It has the function of soft start when closing the battery switch, which can eliminate the starting inrush current, protecting both the machine and the battery.
The PV power can reach up to twice the rated power, and it simultaneously supports full-power grid connection as well as charging and energy storage.
It adopts three - stage charge - discharge conversion, which results in low current ripple and prolongs the service life of the battery.
The Maximum Supports up to 15 parallel machines,Meet users' capacity expansion needs.
It is equipped with a multi-functional generator interface, enabling intelligent switching and control, thus saving additional investment.
Both the AC input port and the generator interface can be connected to the PV grid-connected inverter for renovating the original PV system.
4.3-inch 65K-color HD touch screen, supporting customization of languages worldwide.
Set the charging and discharging time periods according to the time-of-use electricity price.
With an IP66 protection rating, it can be installed outdoors.
| MODEL | HB1030 | EH048 | HB1036 | EH048 | HB1040 | EH048 | HB1046 | EH048 | HB1050 | EH048 | HB1055EH048 | HB1060 | EH048 | HB1080 | EH048 | |||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| PV Input | ||||||||||||||||||||||
| Max PV Input Power | 6000W | 7200W | 8000W | 9200W | 10000W | 11000W | 12000W | 16000W | ||||||||||||||
| Max PV Input Voltage | 550Vdc | |||||||||||||||||||||
| PV Input Startup voltage | 90Vdc | |||||||||||||||||||||
| MPPT Input Voltage | 370Vdc(90~550V) | |||||||||||||||||||||
| MPPT Full Load Voltage Range | 210~550Vdc | 250~550Vdc | 140~550Vdc | 160~550Vdc | 175~550Vdc | 195~550Vdc | 210~550Vdc | 280~550Vdc | ||||||||||||||
| PV Max Input Current | 15A | 15A+15A | ||||||||||||||||||||
| PV Short-circuit Current | 20A | 20A+20A | ||||||||||||||||||||
| Number of MPPT / Strings per MPPT | 1/1 | 2/1+1 | ||||||||||||||||||||
| AC Output | ||||||||||||||||||||||
| Rated Output Voltage/Frequency | 220Vac/230Vac/240Vac，50Hz/60Hz | |||||||||||||||||||||
| Grid Voltage Range | Local grid standard mode / Custom mode: 90Vac~280Vac (configurable) | |||||||||||||||||||||
| Rated Output Frequency | 45Hz~55Hz,55Hz~65Hz，Intelligent adaptive | |||||||||||||||||||||
| Rated grid-connected current | 13A | 15.6A | 17.4A | 20A | 21.7A | 23.9A | 26A | 34.8A | ||||||||||||||
| Max Grid-connected Current | 13.7A | 16.4A | 18.3A | 21A | 22.8A | 25A | 27.4A | 38.2A | ||||||||||||||
| Rated Grid-connected Active Power | 3000W | 3600W | 4000W | 4600W | 5000W | 5500W | 6000W | 8000W | ||||||||||||||
| Rated Grid-connected Apparent Power | 3000VA | 3600VA | 4000VA | 4600VA | 5000VA | 5500VA | 6000VA | 8000VA | ||||||||||||||
| Max Off-grid Power | 3150W | 3780W | 4200W | 4830W | 5250W | 5775W | 6300W | 8400W | ||||||||||||||
| DC Component | ＜0.5% In | |||||||||||||||||||||
| Grid Type | Single-phase，L+N+PE | |||||||||||||||||||||
| Output Power Factor | 1 （Adjustable 0.8 leading~0.8 lagging） | |||||||||||||||||||||
| THDi | ＜3% | |||||||||||||||||||||
| THDu | ＜2%(Linear load) | |||||||||||||||||||||
| Transfer Time | ＜10ms(Typical value) | |||||||||||||||||||||
| Off-grid Overload Capability | ＜105%Long-term work , 106%-120% 3min , >120% 10S | |||||||||||||||||||||
| Battery Input | ||||||||||||||||||||||
| Battery Type | Lead-acid, lithium batteries, gel batteries, etc | |||||||||||||||||||||
| Battery Voltage | 48Vdc(40~60V) | |||||||||||||||||||||
| Max Discharge Current | 70A | 90A | 100A | 115A | 120A | 120A | 120A | 150A | ||||||||||||||
| Max Charging Current | 70A | 90A | 100A | 100A | 100A | 100A | 100A | 150A | ||||||||||||||
| Max Discharge Power | 300W | 3600W | 4000W | 4600W | 5000W | 5500W | 6000W | 8000W | ||||||||||||||
| Max Charging Power | 3000W | 3600W | 4000W | 4600W | 5000W | 5500W | 6000W | 8000W | ||||||||||||||
| Efficiency | ||||||||||||||||||||||
| Max PV Conversion Efficiency | 97.6% | |||||||||||||||||||||
| European Efficiency | 97.0% | |||||||||||||||||||||
| MPPT Efficiency | ＞99% | |||||||||||||||||||||
| General Parameters | ||||||||||||||||||||||
| Display | Touch Screen+LED | |||||||||||||||||||||
| Communication Mode | Standard ：RS485/CAN/DRM，Optional 4G/WIFI/GPRS | |||||||||||||||||||||
| Protection function | Over/Under Volt Prot、Over/Under Freq Prot、AC Out SC/OL Prot、Anti-Island Prot、Batt Chg/Dchg OC Prot、Leakage Curr Prot、Insul Imped Prot、Grd Fault Prot、PV Rev Conn Alarm | |||||||||||||||||||||
| Surge Protection | DC Type II / AC Type III | |||||||||||||||||||||
| Noise (dB) | ＜30 | ＜58 | ||||||||||||||||||||
| Cooling | Natural convection | Intelligent fan | ||||||||||||||||||||
| Operating Ambient Temperature | -25°C ~ 60°C(＞45℃ Derating ) | |||||||||||||||||||||
| Humidity | 0~100% | |||||||||||||||||||||
| Altitude | 3000m (>2000m Derating ) | |||||||||||||||||||||
| Electricity Consumption At Night | 15W | |||||||||||||||||||||
| Protection Degree | IP66 | |||||||||||||||||||||
| Installation Method | Wall-mounted | |||||||||||||||||||||
| Dimension. W*D*H(mm) | 505*188*413 | |||||||||||||||||||||
| Gross Weight (kg) | 20 | 24.5 | 25 | |||||||||||||||||||
| Warranty | 5 years standard/10 years optional | |||||||||||||||||||||
| Certifications | ||||||||||||||||||||||
| Certification standard | IEC 62109-2 2011，IEC 62109-1 2010，EN/IEC 50549-10, VDE-4105，EC 60529:1989/AMD:2013，GB/T 4208-2017, EN/IEC 61000-6-3:2021, EN 61000-3-12:2011, EN/IEC 61000-3-12:2019, EN/IEC 61000-6-1:2019, RoHS | |||||||||||||||||||||
Specifications are subject to change without advance notice.
Small household single-phase hybrid energy storage system, suitable for new installation or modification of photovoltaic energy storage system,AC 220V/230V output.
Our Advanced Solar System Inverter is an intelligent, high-performance solution designed for seamless energy management. Equipped with cutting-edge technology, this inverter ensures efficient power conversion, real-time monitoring, and multiple operation modes to meet various energy needs.
Intelligent & Easy Remote Communication
Supports 4G, WiFi, or GPRS for remote monitoring and management.
24-hour load monitoring for real-time insights into energy usage.
Compatible with various battery types, including lead-acid, lithium, and gel batteries, with a built-in battery management system.
Advanced safety protection features, including short circuit, under-voltage, overload, anti-reflux, and PV anti-reverse connection safeguards.
IP66-rated for superior outdoor durability, protecting against dust and water.
Fanless, low-noise design ensures silent operation for both residential and commercial applications.
Integrated MPPT controller with an impressive 99.9% MPPT efficiency for maximum solar energy utilization.
Self-Use Mode: Prioritizes self-consumption.
Selling First Mode: Maximizes energy selling to the grid.
Back-Up Mode: Ensures energy availability during outages.
Force Time Use: Scheduled energy consumption.
Composite Pattern: Customized energy usage strategy.
Grid-connected: Optimized for seamless integration with the power grid.
Off-grid: Ideal for independent power supply.
Bypass mode: Directly powers loads when necessary.
Built-in UPS function with a switching time of ≤10ms, ensuring an uninterrupted power supply.
Dual anti-reflux protection prevents excess power from back-feeding into the grid.
External inspection: Make sure the inverter housing is not damaged, the air inlet is not blocked, there is no dust accumulation, and there is no sign of corrosion.
Internal inspection (requires professional personnel): Check whether the circuit board is dusty and whether the components are aging or loose.
Cleaning method: Use a dry soft cloth or compressed air to remove dust, and avoid wiping directly with water or a wet cloth.
LCD display: Check whether there are warnings or fault codes. If an error code appears, refer to the manual or contact the manufacturer for resolution.
LED indicator: Green indicates normal operation, and red may indicate a fault or error, and the cause needs to be investigated.
Sound check: If the inverter makes abnormal noises, such as humming or high-frequency screaming, it may be a fault in the cooling fan or internal components.
Ensure good ventilation: Inverters are usually equipped with fans or heat sinks, and dust blockage or poor heat dissipation should be avoided.
Temperature monitoring: If the inverter temperature is too high, it will affect the efficiency. Avoid direct sunlight during installation and ensure smooth ventilation.
Tighten the cables: Check the DC input and AC output terminals regularly to see if they are firmly connected.
Prevent oxidation and corrosion: If the terminals are rusted or oxidized, clean them with contact cleaner.
Avoid cable aging: Check the cables for wear, aging or damage, and replace them if necessary.
Regularly record power output, voltage, current and other data, compare them with past data, and promptly troubleshoot any abnormalities.
Use a remote monitoring system (if available): Some smart inverters can monitor the operating status through APP or the cloud, which is convenient for remote diagnosis.
Firmware updates: Check whether the manufacturer provides software or firmware updates to improve system stability and efficiency.
Lightning protection: If there are many lightning strikes in the area, it is recommended to install a lightning arrester and regularly check whether the grounding is good.
It is recommended to ask professional technicians to conduct a comprehensive inspection every 6 months to 1 year to ensure long-term stable operation of the system.
Doing these maintenance tasks well can greatly improve the efficiency of the solar system and extend the life of the inverter.
